Accu-Gold - Ion Chamber measurements while using a multi‐sensor as a trigger

• Connect the Chamber/AGMS/Dose‐Diode
• Open Accu‐Gold
• Click the "Start" Button and standby by for the initialization process
• When the system is in the "Ready" state click "Settings" in the lower‐right corner of the interface

• By default (on Automatic profile) the AGMS should be the default trigger, if it is not,
click on "AGMS" from the Trigger Source field.
• The system will re‐initialize. Once in the ready state you can begin to measure using the
solid state sensor as the trigger source.

This instruction works for all solid state sensors: AGMS/Dose‐Diode
