Question
How do I use the End-to-End Test Inserts with the myQA SRS system?
Answer
Two End-to-End test inserts are available for use with the myQA SRS system:
- The Winston-Lutz Insert is designed to verify the radiation isocenter using EPID Imaging. The acquired EPID images are transferred to a machine with the IsoTrack Plugin installed. Supported in myQA 2022-001 and later versions.
- The End-to-End (E2E) Imaging and Planning Insert (I&P) is used to simulate the whole patient workflow, from CT acquisition to treatment irradiation, including treatment planning and setup in the treatment room. Supported in myQA 2023-001.
For both inserts, the product information, instructions for use, and technical specifications can be found in the myQA SRS Instructions for Use (Document ID: P-20-003-510-001u 03):
- Product information: Section 2.2.4.3, pages 12-13
- Instructions for use: Section 3.4.1, page 29
- Technical specifications: Section 6.2, pages 42-43
Additional information on analyzing measurements obtained with the inserts can be found in the
myQA Machines Instructions for Use (Document ID: P-22-004-510-003u 01):
- Winston-Lutz Insert: Chapter 8, pages 66-71
- End-to-End Imaging and Planning Insert: Chapter 10, pages 79-84 (pre-defined E2E templates available in myQA 2023-001)
The most up-to-date Instructions for Use can be found in the Support Portal (iba-portal.com).
-
- Login to the support portal and click DOWNLOADS.
- Select the correct product from the drop-down list and click SEARCH.
- Click on the name of the correct document to open and download it.
Quickly access the Support Portal using the QR code:
